| Parameter | P1.25 | P1.875 |
|---|---|---|
| Pixel Density | 640,000 px/㎡ | 284,089 px/㎡ |
| LED Chip | Flip Chip | |
| Module Size (W*H) | 150*168.75mm | |
| Module Resolution | 120*135 dots | 80*90 dots |
| Surface Treatment | Matt COB | |
| Surface Hardness | 4H | |
| Panel Size (W*H*D) | 600mm*337.5mm*42mm | |
| Panel Weight | 4.5 kg / panel | |
| Panel Resolution (dots) | 480*270 | 320*180 |
| Material | Die-casting Aluminium | |
| Circuit Design | Common Anode Circuit | |
| Flash Correction Storage | Applicable | |
| Brightness | Standard 600nits | |
| Refresh Rate | 3840Hz | |
| Contrast Ratio | 20000:1 (Condition without lighting) | |
| Color Temperature | 9300K (Standard) | |
| Viewing Angle | H160°, V160° | |
| Input Voltage | AC 220 or 100~240V 50/60Hz | |
| Max. Power Consumption (White Balance 600nits) | 70 w/panel | 70 w/panel |
| Maintenance Way | Front Service | |
| IP level of PCB surface | IP65 (Washable by clean water) | |
| Lifetime at 50% Brightness | 100,000 hours | |
| Operating Temperature / Humidity | -10°C-+40°C/10%RH-90%RH | |
| Storage Temperature / Humidity | -20°C-+60°C/10%RH-90%RH | |
| Certificate | CCC, EMC CLASS-A, ROHS, CQC | |
| Application | Indoor | |
| Warranty | 3 years | |
The standard COB cabinet (600×337.5mm) adopts a hard-connection design with a non-customizable panel size. It is equipped with a customized Megmeet wide-voltage power supply (100~240V, non-selectable) and offers optional NovaStar receiving cards (A10s Pro, A8s-N, A8 Plus-N). Free logo printing is available on the cabinet back.
